TP70 (3 Axle)
The Tractive Power TP70 is a versatile and robust industrial locomotive designed for a wide range of rail applications. With a focus on efficiency and reliability, the TP70 is capable of handling various tasks in rail yards and industrial settings. Its powerful tractive effort and advanced features make it a valuable asset for tasks such as shunting, switching, and hauling heavy loads, ensuring smooth and efficient rail operations.
Weight
200,000 LB
Speed
25 MPH
Engines
400hp to 513hp
Tractive Effort
Starting (35% adhesion)
70,000 LB
Power in Numbers
Minimum Curve
193-foot radius (30 degrees)
Dimensions
Length: ( between pulling faces) 33’ – 8” ( 404” )
Length: 29’ – 10” ( 358” )
Width: 10” – 3” ( 123” )
Height: 14’ – 2-3/4” ( 170.8” )
Air Brakes
Type 26 L
Control
AAR Standard
Traction Motors
D-77 or D-78 (3 units)
Air Compressor
Rotary Screw Type – 200 CFM
Generators
Brushless alternator
Wheel Base
Wheel Base: 13’ – 7” ( 163” )
Wheel Diameter: 40”
Fuel Capacity
300 gallons and up
